NOYAFA Cable and Network tester NF-488 NEW LCD Network PoE Checker Over The Ethernet cat5 cat6 Lan Cable Tester Loop Test Tool, Power over Ethernet (PoE) Checker Tester

Produktbeschreibung

• 【Identify af / at Standard Automatically】Quickly check power sourcing equipment (PSE) type, the IEEE802.3af or 802.3at standard. 【Inline Power Testing】Inline test info of standard/non-standard PoE devices, including power supply voltage, power supply polarity, crossover mode, and more.
• 【Cable Continuity Testing】Test the short circuit, crossover and open circuit status for STP, UTP lan cable. 【Loopback Testing】Test the loop circuit connected to switch is normal or not. 【Lamp】A lamp is equipped in main unit, helps work in darkness.【Certification】 Passes RoHS, FCC and CE compliance testing, and Noyafa is certified to the ISO 9001 standard.
• Specifications: Material: ABS Transmitter Specification: CONTINUITY FUNCTION: Cable Types: STP/UTP Max Testing Range: 600m Wire Mapping: Emitter + remote, emitter + switch/routor.POE FUNCTION: Test Range: DC5-60V PoE switch Standard Identify: 802.3af/at(standard/non-standard) Test Range Power: 0-18W
• POWER FUNCTION: Voltage Test Range: DC0-60V Current Test Range: 0-3A Power Test Range: 0-180W.Display: LCD 128*64mm, with back light Input Voltage Protection: DC48V, 5mA Max Working Current: ≤80mA Loopback: Compatible with 10M, 100M,1000M switch Power Supply: 3 * 1.5V AAA battery (Not included)
• Remote Specification: Ports: RJ45 Function: Wire mapping for network cable Input Voltage Protection: DC48V, 5mA.Emitter Size: Approx. 12.5 * 7 * 2.8cm / 4.92 * 2.76 * 1.1in Remote Size: Approx. 6.5 * 3.7 * 2.3cm / 2.56 * 1.46 * 0.91in Emitter Weight: Approx. 123g / 4.33oz Remote Weight: Approx. 24g / 0.86oz Package Weight: Approx. 301g / 10.64oz Package Size: Approx. 22.5 * 11 * 4cm / 8.86 * 4.33 * 1.58in
